1000′ RG6/U 18AWG 3GHz CCS 60% AL BRAID CMR / CATV 6CCSCMRRB
Description :
Commodity Cables Inc. Model 6 CCSCMRxx, RG6/U Copper Clad Steel 18 AWG CMR U/V 3000 MHz, xxx Feet MM/YY (foot mark in descending order)
Also Know As :
RG6/U Cable, Braid CMR, Braid CMR Cable, 18 AWG Braid CMR Cable.
Applications:
- Indoor for CATV, MATV, and SMATV
- Outdoor for Digitalb Satellite Reception
Standard Compliances:
- • ANSI/TIA 568-C.2
- • ANSI/TIA 862 (Building Automation)
- • ISO/IEC 11801 Ed. 2.0 (Class EI)
- • ICEA 8-102-700 (Category 6 or 5E)
- • REACH Compliant
- • CPR Compliant (Fully Complies to 305/2011 & EN 50575:2014-09)
- • RoHS Compliant Directive 2002/95/EG
Electrical Characteristics:
- Product Rating: CSA
- Flammability Test: CMR / CATV / CL2
- Nominal Capacitance: 16.2 pf/ft
- Max. Conductor DC Resistance Unbalance (%) 53.1 pf/ft
- Nom. Impedance: 75 ohm
- Temperature Range: -20 ~ 750C
- Velocity of Propagation (%) NVP: 45
Physical Properties:
- • Conductor Material: Solid Copper Covered Steel
- • Insulation Material: Gas Injected Foam FEP
- • Shield Number: 2
- • Construction: Non-Plenum/ CMR / Dual Shield
- • Temperature Range: -20°C to 75°C
Specification :
- • Size AWG: 18
- • Conductor Nominal O.D (mm): 0.040 in. (4.57 mm)
- • Insulation Diameter (mm): 0.18 in. (4.57 mm)
- • Packing: 1000 FT/DRUM
- • Packing Length: 1000ft
- • Weight: 32 lbs
- • Part No: 6CCSCMRXX
