104302 LÜTZE SUPERFLEX® ETHERNET (C) PUR (2×2×AWG22/19)C Network Cable
104302 LÜTZE SUPERFLEX® ETHERNET (C) PUR (2×2×AWG22/19)C Network Cable
Allowable Ampacity for 104302 LÜTZE SUPERFLEX® ETHERNET (C) PUR (2×2×AWG22/19)C Network Cable: 100 Amps
Application:
• For the cabling of industrial field bus systems with the globally accepted TCP/IP protocol
• For continuous flexing use e.g. in c-tracks or free movement in the automation technology, transport and conveyor technology, machine tool manufacture
Also Known As:
104302 LÜTZE SUPERFLEX, 104302 ETHERNET (C) Cable, SU ET (C) PUR (2×2×AWG22/19)C Cable, Lutze Cable, PUR Network Cable, Network Cable, Superflex Cable, Silicone-free Cable, Tinned Copper Cable, Flexible Cable
Properties:
• High active and passive interference resistance (EMC)
• Silicone free
• Halogen free
• RoHS‐compliant
Standards:
Certifications:
• CE
• RoHS
• REACH
Burning behavior according to:
• IEC 60332-1
• DIN EN 60332-1-2
• VDE 0482 322-1-2
• UL 1581 Part VW-1 Flame Test
• UL FT1
Halogen free according to:
• DIN EN 60754-1
• IEC 60754-1
Construction:
- • Conductor construction: AWG 22/19
- • Conductor: AWG conductor CU-wire bare
- • Conductor marking: blue, white, yellow, orange
- • Conductor insulation: Special Polyolefin
- • Overall stranding: star quad stranding
- • Overall shield: braid shield tinned copper wires optical cover approx. 85%
Jacket characteristics:
- • Flame-retardant
- • Silicone-free
- • Halogen free
Technical data:
- • Rated voltage: 300 V
- • Test voltage type: AC1500V
- • Temperature range moving: -30 °C … +70 °C
- • Temperature range fixed: -40 °C … +80 °C
- • Minimum bending radius moving: 12×D
- • Minimum bending radius fixed: 6×D
- • Category: Cat.5e
- • Ethernet Key: S/UTQ
- • Operating capacitance wire-wire: 48 pF/m
- • Loop resistance: 110 mΩ/m
- • Impedance: 100 Ω
Specification:
- • Number of conductors/cross-section: (2×2×AWG22/19)C
- • Cross-section AWG: AWG 22
- • Cross-section, metric: 0.34 mm²
- • Jacket material: PUR
- • Jacket color: green RAL 6018
- • Surface: adhesion-free matt
- • Outer Ø: 0.26 Inches
- • Weight: 52.50 Lbs
- • Cu-Index: 21.3 Lbs
- • Type: SU ET (C) PUR (2×2×AWG22/19)C
