14 AWG 259/36 Strand BC Unshielded PVC Series 208 CL2x Clear 150V Low Voltage Parallel Speaker Wire
14 AWG 259/36 Strand BC Unshielded PVC Series 208 CL2x Clear 150V Low Voltage Parallel Speaker Wire
Allowable Ampacity for 14 AWG 259/36 Strand BC Unshielded PVC Series 208 CL2x Clear 150V Low Voltage Parallel Speaker Wire: 100 Amps
About:
• This speaker wire consists of 259 strands of 36 gauge bare copper (BC) conductors. It is designed for low voltage applications, particularly for use in speaker systems where clear and reliable audio transmission is crucial. The wire is unshielded and features a PVC jacket, providing durability and flexibility.
Also Known As:
• Speaker Wire
• Gauge Audio Cable
• Strand Bare Copper Wire
• Clear PVC Speaker Cable
Application:
• Audio and Speaker Systems
• Home Theater Installations
• Public Address Systems
• Sound Systems in Commercial Spaces
• Low Voltage Signaling
Standard:
• CL2x Rating (suitable for in-wall installation)
• UL Listed (compliance with safety standards)
• RoHS Compliant (Restriction of Hazardous Substances)
Construction:
• Conductor: bare copper
• Insulation: Clear PVC (Polyvinyl Chloride)
• Configuration: Parallel wire configuration
• Voltage Rating: 150V
Features:
• Flexibility: Easy to route and install, even in tight spaces.
• Durability: PVC insulation provides protection against physical damage and environmental factors.
• Signal Integrity: Bare copper conductors ensure clear and reliable audio transmission.
• Compatibility: Suitable for a wide range of low voltage audio applications.
• Visibility: Clear insulation allows for easy identification and troubleshooting.
Specifications:
• AWG: 14
• Stranding: 259/36
• Nominal O.D.: .108 x .118
• Weight (Lbs/Mft): 31
• Part Number: 208142B
