20/2 Thermostat 4X500′ Metal Reel Box Brown UV 2000ft
20/2 THERMOSTAT 4X500′ METAL REEL BOX BROWN UV 2000 FT
Applications:
Used for power limited circuits such as thermostat, air conditioning and heating controls, heat pumps, bell and alarm systems, intercom systems, door bells, remote control units where maximum voltage does not exceed 30 volts.
Specification:
Size: 20 AWG
No. of Cond.: 2
Insulation Diamter: 1.45mm
Jacket Thickness: 0.4mm
Nominal jacket diameter: 3.2 X 2.0 mm
Standard Lengths: 2000′ (2000′ X 4)
Conductors:
The cable has a Annealed Solid bare copper.
Insulation:
FR-PVC.
Jacket:
- FR-PVC White
- Suitable for use from -20°C to +75°C
- Evey 2 feet sequential marking.
Compliances:
- UL type CL3
- UL type CL2
Approvals:
- Industry Approvals:
- Cl3 Cl2-power Limited
- Nec Article 725
- Sunlight Resistant
- Rohs Reach
Color Code:
|
No.of Cond. |
Color |
No. of Cond. |
Color |
|
1 |
Red |
7 |
Orange |
|
2 |
White |
8 |
Black |
|
3 |
Green |
9 |
Pink |
|
4 |
Blue |
10 |
Gray |
|
5 |
Yellow |
11 |
Tan |
|
6 |
Brown |
12 |
Purple |
