20 Amp NEMA L6-20P Black-White Locking Plug 2321
[pdf] [/pdf]
Also known as:
Leviton 2321 Locking Plug, L6-20P 2P 3W Locking Plug AC Industrial Grade, Leviton 20 Amp 250V Industrial Grade, 2321 NEMA L6-20P 2P 3W Locking Plug, Hubbell Locking Plug.
Specification:
| Amperage | 20 A |
| Dielectric Voltage | Withstands 2000V per UL498 |
| Voltage | 250 VAC |
| Wire | 3 |
| Flammability | Rated HB or better UL94 |
| Assembly Screws | Steel, Zinc Plated |
| Body Material | Impact Modified Nylon |
| Wire Module | Nylon |
| Blades/Contacts | Solid Brass |
| NEMA | L6-20P |
| Color | Black-White |
| Part No. | 2321 |
20 Amp NEMA L6-20P Black-White Locking Plug 2321
Description:
20 Amp, 250 Volt, NEMA L6-20P, 2P, 3W, Locking Plug, Industrial Grade, Grounding – Black/White
• One piece contacts reduce friction and overheating
• Unique cord clamp accepts wide range of cord sizes (.245″-.700″)
• Rugged nylon construction resists impact, sunlight, chemicals, and rough use
• Industry exclusive limited lifetime warranty
• Ideal for motor loads, such as shop vacs and pool pumps, and generators
Application:
Locking Plugs And connectors, flanged inlets, and outlets offer superior performance and long-lasting reliability.
