22000MAH,12S1P, 44.4V, 25C With AS150U Plug
| Balancer Connector Type: | JST-XHR |
| Connector Type: | AS150U |
| Configuration: | 12S1P |
| Capacity(mAh): | 22000 |
| Discharge Rate (C): | 25 |
| Height(±2mm): | 4.56 (116mm) |
| Length(±5mm): | 9.25″ (235mm) |
| Width(±2mm): | 6.77″ (172mm) |
| Max Burst Discharge Rate (C): | 5800 |
| Voltage(V): | 44.4 |
| Wire Gauge: | 8# |
Description:
The Plus 1.0 12S series is designed for a range of applications, including agricultural plant protection, security mapping, and power inspection across various industries. This comprehensive system encompasses features such as data acquisition, security alerts, power calculations, automatic equalization, and charging notifications. Additionally, it includes discharge spark prevention, support for charging via a charging butler, alarms for abnormal states, human-computer interaction, historical data queries, and parameter configuration. Users can also monitor the battery pack’s status and access historical working data through the CAN/SMBU communication port and dedicated software on the host computer.
Features:
• Automatic Equalization balances the cells in the battery pack to extend life and enhance performance.
• Discharge Anti-Sparking: Prevents sparking during discharge, enhancing safety.
• Data Acquisition: Captures and analyzes data to optimize performance and efficiency.
• Parameter Configuration: Enables customization of settings to meet specific operational needs.
• CAN/SMBU Communication: Facilitates communication with host computer software for advanced monitoring and control of the battery system.
