250′ 1/0 AWG Welding Cable Class K 600V Cable
[pdf] [/pdf]
[short]
1/0 AWG Welding Cable Class K 600V Cable
Allowable Ampacity For 1/0 AWG Welding Cable Class K 600V Cable: 190 Amps
Also Known As:
1/0 Class K 90C 600V Bare Copper Temporary Power Cable, 1/0 Class K 90C 600V Bare Copper Flexible Power Cable, 1/0 Class K 90C 600V Bare Copper Welder’s Cable, 1/0 Class K Welding Lead Wire, 1/0 Class K Welding Ground Lead, 1/0 Class K Copper Welding Lead, 1/0 welding wire.
Applications:
Welding Class K Bare Copper Cable is used in secondary voltage resistance welding leads and power supply applications not exceeding 600 volts AC. The electrical cable is flexible, abrasion-resistant, and has excellent color retention.
Welding cables are specially designed to power arc welding machines and deliver electric current to the welding application. They are made to be extremely flexible and durable to withstand the harsh conditions of welding operations, including high temperatures, mechanical stress, and exposure to metal particles and slag. Here are some common applications for welding cable:
- Arc Welding Machines
- Battery Connections
- Power Supply Applications
- Emergency Power
- Magnet Cranes
- Earth Clamps
1/0 AWG Welding Cable Class K 600V Cable Uses
Primary Uses
Heavy-Duty Welding: Used in connecting welding machines to electrodes and ground clamps in heavy-duty welding applications where higher currents are needed.
Industrial Equipment: Suitable for powering high-current machinery in industrial settings, where durability and high current-carrying capacity are essential.
Secondary Uses
Battery Connections: In automotive, marine, or solar installations where high-current connections are needed between batteries, or between batteries and inverters.
Emergency Generators: Can be used to connect portable or stationary generators to distribution equipment or directly to critical loads during emergencies.
Electromagnetic Cranes: In industrial settings, for supplying power to heavy-duty electromagnetic lifting cranes.
Mining Operations: Sometimes used for powering heavy equipment in mining operations, given the cable’s robustness and high current-carrying capacity.
Welding Cable Standards:
- RoHS Compliant
Welding Cable Construction:
Conductor:
Fully annealed stranded bare copper, class K stranding.
Jacket:
Black premium-grade Ethylene Propylene Diene Monomer (EPDM) is flexible, durable, and resistant to moisture.
Welding Cable Specification:
- AWG Size: 1/0
- Conductors Strands: 1
- Conductor Type: 990/30
- Jacket type: EPDM
- Color: Black
- Insulation: NONE
- Voltage rating: 600V
- Temperature: 90C
- Outside Diameter: 0.560
- Lbs./M’: 400
|
Compatible with Manufacturer |
|
| Coleman : | Black : 10415 |
| General Cable : |
Black : 1774 Red : 01774.41.03 |
| Omni Cable : |
Black : B21/001 Red : B21/001-03 |
| Southwire : |
Black : 57006099 Red : 1774 |
| Houston Wire : | Black : HW25310101 |
| Kalas : | Red : 650007.03.003 |
| AZ Wire item : | Black : 5WC-1011 |
| AWC : | Black : WELD-1/0 |
| Priority Wire & Cable : | Black : WELD-1/0 |
[/short]
| CONSTRUCTION | |
|---|---|
| Conductor |
|
| Jacket |
|
Applications:
- Secondary voltage resistance welding leads
- Power supply applications not exceeding 600 volts AC
Features:
- Good flexibility
- Abrasion-resistant
- Good Color retention
Standards:
- RoHS compliant
